ALIGN G800M Aerial Gimbal System for Multicopter/Wire CAM(WOC)

G800은 Pro 사양의 3축 짐벌 시스템으로서 독립적인 디지털 서보 3개가 탑재되어 있으며, ALIGN만의 독특한 리버스 위시본 System에 의한 최상의 Image Stabilizing을 구현한 업무용 3축 짐벌 시스템입니다.

5D MK-II/III 및 RED EPIC, SCARLET까지 마운팅이 가능하며(단렌즈에 한함) APS와 데이터링크를 통해 연동되는 시스템입니다.

3축 짐벌 어셈블리, 짐벌 서포트 및 Gimbal Shock이 모두 포함된 수퍼 콤보 세트입니다.(짐벌 컨트롤러는 별매)

국내 사용자들을 위해 별도의 한글매뉴얼과 함께 공급이 됩니다!

별매 짐벌 컨트롤러 바로가기(클릭!)

ALIGNRC G800 Aerial Gimbal Full System!

G800 Test Flying by AKFly!　

G800 Setup Instruction!

1. Carbon Frame 사양의 3축 Gimbal Set

3K Carbon 구성, Back Bone은 경량 알루미늄 합금으로 제작.

5D MarkIII/RED EPIC, SCARLET까지 마운팅이 가능한 High Payload.

하드한 랜딩에도 버틸 수 있는 서스펜션 시스템 구성.

아울러 540도 회전가능한 전용 DS815 디지털 서보 및 Belt Driven 시스템 조합으로 보다 정확하면서도 정밀한 제어 기능.

2. 540도 회전이 가능한 DS815 HV Digital High Voltage 서보 채용.

Soft Start 기동 프로그래밍 설계로 영상 이미지 튐 현상 개선.

- Operating Volatge : DS4.8~7.4V

- 동작 온도 : -20℃~-60℃

- 회전 각도 : 540도

- Dimension : 40.1x20.1x20.7mm

- 최대 토크 : 15kg.cm(4.8V)

18kg.cm(6.0V)

20kg.cm(7.4V)

- 최대 스피드 : 0.15sec/60°(4.8V)

0.13sec/60°(6.0V)

0.11sec/60°(7.4V)

3. 공진 감쇄를 위한 Gimbal Shock Absorb' 어셈블리.

페이로드에 따라 사용자가 임의로 텐션 조절이 가능한 쇽 옵서버 포함!

4. Aluminum Alloy Reverse Wishbone Type 짐벌 서포트 시스템.

독특한 리버스 위시본 타입의 짐벌 서포트, 원터치 구성으로 손쉽게 장,탈착이 가능하며 비행 중 짐벌은 서스펜션이 움직이더라도 항상 동일한 방향을 향하도록 설계.

<Instruction(DS815HV Robot Servo Section>

●Align G800 gimbal is an upgrade product catered specifically for the needs of aerial photography. The included GS800 gimbal controller features high power computing capability, and various control modes to precisely lock into the shooting object, as well as meet the needs of various other aerial photography needs, allowing optimal imagery to be obtained easily. This system must be used in conjunction with Align's APS gyro and T-Rex 800E. 3k carbon composite material matched with high strength aluminum alloy to form the gimbal backbone, featuring high precision, high stability, capable of high payload, and is able to sustain hard landing of helicopter. When paired with 540 degrees DS815 servo and belt transmission design, the gimbal is capable of wider turning angles with higher precision.
●Unique gimbal support assembly design, with aesthetic pleasing clean look, featuring high precision and slop free and makes the camera lens maintain at the same angle in flight.
●Shock absorbing dampners designed specifically for Align GS800 gimbal system, posses superior vibration dampening effect, and various spring tensions can be used according to payload.

* Specification

- Characteris Tic: Soft Start
- Rating Voltage:DC4.8~7.4V
- Temperature Range:-20℃~60℃(-20°~140℉)
- Operating Range:540°(1000~2000us)
- Broadband Systems:1500μs
- Stall Torque:15kg.cm(4.8V)
- 18kg.cm(6V)
- 20kg.cm(7.4V)
- Motion Speed:0.15sec/60°(4.8V)
- 0. 13sec/60°(6V)
- 0.11sec/60°(7.4V)
- Dimension:40.1x20.1x20.7mm
- Weight:66g

* Specification(GS800 Controller)

- Rating Voltage:DC4.8~8.4V
- Temperature Range:-40°C~125°C (-40°~257°F )
- Operating Current Consumption:
- 55mA@ 6V(ROLL)
- 40mA@ 6V(PAN)
- Maximum Control range:
(ROLL) ±30°
(PAN) ±90°
(TILT) ±90°
- Maximum Control rotation Speed:
(ROLL) 60°/ s
(PAN) 150°/ s
(TILT) 150°/ s
- Dimension:42.7x 30 x 14.2mm
- Weight:11g

<Features>

●Gimbal features 3k carbon composite material matched with high strength aluminum alloy to form the backbone, featuring high precision, high stability, high payload capability, and is able to sustain hard landing of helicopter.
●Utilizes 540 degrees DS815 high voltage robotic servos, supporting 2s 7.4v input voltage. Special slow start feature to avoid jerky start-ups.
●Unique gimbal support assembly design, with aesthetic pleasing clean look, featuring high precision and slop free and makes the camera lens maintain at the same angle in flight.
●Shock absorbing dampners designed specifically for Align GS800 gimbal system, posses superior vibration dampening effect, and various spring tensions can be used according to payload.
●GS800 gimbal controller is a highly stable, highly precise 3-axis gimbal control system. Featuring 5 control modes: mode 1 -three axis auto compensation; mode 2 - two axis auto compensation; mode 3 -three axis return to neutral; mode 4 - manual; mode 5 - rescue mode. These various modes will meet the variety needs of aerial photography.
●Simple to setup. Complete setup can be done with two steps.
●Unique rescue mode, to minimize photography equipment damage during a crash.
●Supports lens zoom in and zoom out feature.
●Supports shutter activation. Follow the instruction to connect shutter with GS800 controller, shutter can be activated via transmitter stick through GS800.
●Supports Spektrum/JR satellite receivers and Futaba S.BUS architecture.
●Upgradeable firmwareinterface, allowing firmware updates through interface cable.
●Must be used in conjunction with Align APS gyro and 3GX flybarless system, enabling gimbal control system to achieve high stability and excellent controllability.

<Accessories>

- G800 GIMBAL x 1 set
- Gimbal Support Assembly x 1 set
- Gimbal Shock Absorbers Assembly x 1 set
- DS815 HV Robor Srevo x 3 set
